28MM MANIFOLD KWW TYPE-1B (CRF110i/W110i/DREAM 110i)

YUMINASHI 28MM MANIFOLD KWW TYPE-1B (CRF110i/W110i/DREAM 110i) (17110-KWW-28272L)

Hover over image to zoom

  • YUMINASHI 28MM MANIFOLD KWW TYPE-1B (CRF110i/W110i/DREAM 110i) (17110-KWW-28272L)
YUMINASHI
฿1,450.00
SKU:
17110-KWW-28272L
Weight:
180.00 Grams
Availability:
Fast moving item, ships the next day (Except on Sundays and Thai public holidays)...
Shipping:
Calculated at checkout
Minimum Purchase:
1 unit(s)
Buy in bulk and save

 Product Description

buying-2-discount-300pxl-.png● YUMINASHI KWW TYPE-1B 28MM MANIFOLD (CRF110i/W110i/DREAM 110i) FOR B-TYPE INJECTOR

● Choosing the “right” intake manifold for an engine is just as important as choosing the right camshaft, cylinder head and compression ratio, since all of these components have to complement one another and work in harmony together otherwise the engine will never realize its true power potential.

● This Yuminashi Type-1B manifold is a KWW "110-type" throttle body, plug & play ready to be installed on a 28mm throttle body (1.102 inches) and B-type injector.

● The exact diameter of this KWW Type-1 manifold at throttle body side is 30mm (1.102 inches), the diameter at the intake port side is 27.2mm (1.07086614 inches).

● This manifold is mentioned to be used in combination with a "110cc engine type" throttle body such as the CRF110 PGM-FI or the WAVE110i / DREAM SUPER CUB 110i throttle body.

※ The bolts distance from a "110-type throttle body" are from center to center 62mm.

※ The color can be grey (aluminium color) or black, depending on the production.

※ Keep in mind that this manifold is a B-type manifold mentioned for a B-type injector.
If your bike is produced before 2013, then there is a big chance you will have a A-type manifold and injector installed.
If this is the case, then you can find the correct B-type injectors for this manifold with this LINK, and the wire loom to connect the B-type injector to your A-type injector wire harness you can find with this LINK.

 ● THE YUMINASHI KWW TYPE-1B MANIFOLD IS MENTIONED TO BE INSTALLED ON:

HONDA:

  • CC110 CROSS CUB 110 (2018- )
  • CRF110F PGM-FI (2018- )
  • DREAM 110i (2011 - 2018)
  • WAVE 110i (2011 - 2013)
  • WAVE 110i (2013 - 2017)
  • WAVE 110i (2017- )

budget-logo-2.png SMART SHOPPER TIP:

       ※ BUYING MORE THAN 1 PIECE CUT THE TRANSPORT PRICE, AND YOU RECEIVE A 10% DISCOUNT ON TOP OF IT!

   ※ B2B:

  • Purchases between 2 & 4 pieces of this product will receive a 10% DISCOUNT
  • Purchases between 5 & 9 pieces of this product will receive a 15% DISCOUNT
  • Purchases between 10 & 19 pieces of this product will receive a 20% DISCOUNT
  • Purchases between 20 & more pieces of this product will receive a 25% DISCOUNT
